Chauvet Maverick Force S Spot

Description

Chauvet Maverick Force S Spot is ideal for small to medium multi-faceted projects in need of seamless colour-mixing, advanced optics, and control options in a lightweight frame, well under 50 lbs.

The compact unit features a smart optical system that maximizes the output of 14,000 lumens and provides high-quality colour-mixing with a CTB filter. An 8-slot colour wheel is also added with split-colour combinations in mind. Maverick Force S features a speedy effects engine that includes motorized iris, frost, focus, a 5-facet prism, and wide zoom ranging from 4° to 43°.

Additionally, custom gobos created in collaboration with leading designers can be stacked on top of one another for dynamic effects. That is a lot packed in a small frame standing just over 2 ft tall. Control as you see fit with DMX, sACN, Art-Net or W-DMX.

FEATURES:

  • Fully featured, compact and lightweight 350 W LED yoke spot fixture including CMY colour mixing, a colour wheel, zoom optics, and two gobo wheels, one rotating, and one static
  • 16-bit dimming of master dimmer for smooth control of fades
  • Variable CMY colour mixing system to create a wide pallet of colours
  • DMX, WDMX, sACN, and Art-Net for full flexibility of control options
  • RDM Enabled for remote addressing and trouble shooting
  • 4.1° to 43.4° zoom range for variable beam sizes
  • Iris, 5-facet prism, and frost for beam control
  • True 1 compatible power input
  • Three setup menu presets and preset sync for cross loading to multiple like fixtures for easy shop setup
  • USB slot for software uploads
  • Battery backup display with auto-rotate depending on fixture orientation

SPECIFICATION:

OPTICAL

  • Light Source: 1 LED (CW) 350 W, (2.7 A), 8400 K, 50,000 hours life expectancy
  • Colour Temperature (at full): 6858 K
  • CRI: 68.6
  • CRI with CRI filter: 89.6
  • Front Lens Diameter: 119 mm
  • Beam Angle: 4.1° to 36.5°
  • Field Angle: 5.1° to 40.4°
  • Cutoff Angle: 5.4° to 43.4°
  • Zoom Range: 4.1° to 43.4°
  • Lumens - Source: 20,000
  • Lumens – Output: 14,407
  • Illuminance (4.1°): 62,131 lux @ 5 m
  • Illuminance (43.1°): 1,745 lux @ 5 m
  • Selectable PWM: 600 Hz, 1200 Hz, 4000 Hz, 6000 Hz, 15000 Hz

DYNAMIC EFFECTS

  • Pan and Tilt: 540°/270°
  • Pan and Tilt Ranges: 540°, 360°, 180° pan/270°, 180°, 90° tilt
  • Colours: 7 (including CRI and CTB filters) + white, split colours, continuous scroll at variable speeds
  • Colours: CMY Wheels
  • Gobos (1): 7 + open (glass), rotating, interchangeable, indexing, slot-n-lock, continuous scroll at variable speeds
  • Gobos (2): 9 + open (metal), static continuous scroll at variable speeds
  • Gobo Size (1): Gobo Wheel 1 (rotating): 25.5 mm (outside), 17 mm (image), 1.1 mm (max. thickness)
  • Dimmer: Electronic
  • Shutter/Strobe: Electronic
  • Zoom: Motorised
  • Focus: Motorised
  • Frost: Motorised
  • Iris: Motorised
  • Prism: 5 Facets, motorised, rotating
  • Strobe Rate: 0 to 20 Hz
  • Move-in-Black: Yes
  • Dim Curves: 4

CONSTRUCTION / PHYSICAL

  • Dimensions: 14 x 8.8 x 25.0 in (360 x 224 x 636 mm)
  • Weight: 47.4 lb (21.5 kg)
  • Exterior Colour: Black
  • Housing Material: High-impact flame-retardant polymer

CONNECTIONS

  • Power Connection: Edison plug to Seetronic Powerkon IP65
  • Power Input: Seetronic Powerkon IP65
  • Data Connectors: 3-pin and 5-pin XLR, Amphenol XLR Net RJ45 Connectors in/out
  • Cable Length (power): 5 ft (1.5 m)

CONTROL

  • Control Protocol: Art-Net, sACN, DMX, RDM, W-DMX
  • DMX Channels: 22 or 29
  • Art-Net Channels: 22 or 29
  • Modes/Personalities: 2 personalities (22, 29)

ELECTRICAL

  • Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)
  • Power Linking: 2 units @ 100 V; 2 units @ 120 V; 5 units @ 208 V; 5 units @ 230 V; 5 units @ 240 V
  • Power and Current: 554 W, 5.54 A @ 100 V, 60 Hz[6.0 A in-rush]
  • Power and Current: 542 W, 4.53 A @ 120 V, 60 Hz[7.0 A in-rush]
  • Power and Current: 522 W, 2.58 A @ 208 V, 60 Hz[15.0 A in-rush]
  • Power and Current: 521 W, 2.33 A @ 230 V, 50 Hz[15.0 A in-rush]
  • Power and Current: 521 W, 2.26 A @ 240 V, 50 Hz[15.0 A in-rush]
  • Power and Current (resting): 77 W, 0.904 A @ 100 V, 60 Hz
  • Power and Current (resting): 77 W, 0.701 A @ 120 V, 60 Hz
  • Power and Current (resting): 76 W, 0.418 A @ 208 V, 60 Hz
  • Power and Current (resting): 73 W, 0.375 A @ 230 V, 50 Hz
  • Power and Current (resting): 74 W, 0.368 A @ 240 V, 50 Hz

CERTIFICATIONS / QUALIFICATIONS

  • CE, MET, FCC
  • IP Rating: IP20, dry location
  • Noise Level (ambient): 37.5 dB level @ 1 m
  • Noise Level (Static - Full): 40.9 dB level @ 1 m
  • Noise Level (Static - Eco): 37.9 dB level @ 1 m
  • Noise Level (Static - Auto): 38.4 dB level @ 1 m
  • Noise Level (Max): 45.5 dB level @ 1 m
  • Temperature (startup): -4 °F to 113 °F (-20 °C to 45 °C)
  • Temperature (operating): -22 °F to 113 °F (-30 °C to 45 °C)

Manufacturer: Chauvet

Related Collections:

Product form

SKU: CHV-MAVERICK-FORCE-S-SPOT

Out of stock

£3,560.00 Incl. VAT

    Delivery informationDelivery information

    There is a free standard delivery option for most UK orders as well as a £2.99 option which means your order will arrive faster than normal.

    For standard delivery your order should arrive within 2-5 working days. For the faster option it should be 1-3 working days.

    If you're from Northern Ireland there will be a £5 surcharge for heavier items. If you're buying a light item (under 2kg) please let us know as we may be able to refund your postage after the purchase.

    Buy now pay laterBuy now pay later

    Paypal Pay in 3 lets you spread your purchase interest free over 3 separate payments.

    If you'd like to use Paypal Pay in 3, please perform the following steps.

    1. Add the item to your cart as normal.

    2. Check out with Paypal.

    3. Log into Paypal.

    4. You should see a screen detailing the item costs. Scroll down and you should see an option for "Pay in 3".

    5. Continue the checkout process.

    1/3 of the purchase price will be taken immediately and then the rest over the next 2 months the rest of the payment will be taken.

    Please see more info about the service here.

    As with any sort of buy now pay later, please only use this service for added convenience when making a bigger purchase. It should only be used if you're 100% sure you can make all of the payments on time.

    Description

    Chauvet Maverick Force S Spot is ideal for small to medium multi-faceted projects in need of seamless colour-mixing, advanced optics, and control options in a lightweight frame, well under 50 lbs.

    The compact unit features a smart optical system that maximizes the output of 14,000 lumens and provides high-quality colour-mixing with a CTB filter. An 8-slot colour wheel is also added with split-colour combinations in mind. Maverick Force S features a speedy effects engine that includes motorized iris, frost, focus, a 5-facet prism, and wide zoom ranging from 4° to 43°.

    Additionally, custom gobos created in collaboration with leading designers can be stacked on top of one another for dynamic effects. That is a lot packed in a small frame standing just over 2 ft tall. Control as you see fit with DMX, sACN, Art-Net or W-DMX.

    FEATURES:

    • Fully featured, compact and lightweight 350 W LED yoke spot fixture including CMY colour mixing, a colour wheel, zoom optics, and two gobo wheels, one rotating, and one static
    • 16-bit dimming of master dimmer for smooth control of fades
    • Variable CMY colour mixing system to create a wide pallet of colours
    • DMX, WDMX, sACN, and Art-Net for full flexibility of control options
    • RDM Enabled for remote addressing and trouble shooting
    • 4.1° to 43.4° zoom range for variable beam sizes
    • Iris, 5-facet prism, and frost for beam control
    • True 1 compatible power input
    • Three setup menu presets and preset sync for cross loading to multiple like fixtures for easy shop setup
    • USB slot for software uploads
    • Battery backup display with auto-rotate depending on fixture orientation

    SPECIFICATION:

    OPTICAL

    • Light Source: 1 LED (CW) 350 W, (2.7 A), 8400 K, 50,000 hours life expectancy
    • Colour Temperature (at full): 6858 K
    • CRI: 68.6
    • CRI with CRI filter: 89.6
    • Front Lens Diameter: 119 mm
    • Beam Angle: 4.1° to 36.5°
    • Field Angle: 5.1° to 40.4°
    • Cutoff Angle: 5.4° to 43.4°
    • Zoom Range: 4.1° to 43.4°
    • Lumens - Source: 20,000
    • Lumens – Output: 14,407
    • Illuminance (4.1°): 62,131 lux @ 5 m
    • Illuminance (43.1°): 1,745 lux @ 5 m
    • Selectable PWM: 600 Hz, 1200 Hz, 4000 Hz, 6000 Hz, 15000 Hz

    DYNAMIC EFFECTS

    • Pan and Tilt: 540°/270°
    • Pan and Tilt Ranges: 540°, 360°, 180° pan/270°, 180°, 90° tilt
    • Colours: 7 (including CRI and CTB filters) + white, split colours, continuous scroll at variable speeds
    • Colours: CMY Wheels
    • Gobos (1): 7 + open (glass), rotating, interchangeable, indexing, slot-n-lock, continuous scroll at variable speeds
    • Gobos (2): 9 + open (metal), static continuous scroll at variable speeds
    • Gobo Size (1): Gobo Wheel 1 (rotating): 25.5 mm (outside), 17 mm (image), 1.1 mm (max. thickness)
    • Dimmer: Electronic
    • Shutter/Strobe: Electronic
    • Zoom: Motorised
    • Focus: Motorised
    • Frost: Motorised
    • Iris: Motorised
    • Prism: 5 Facets, motorised, rotating
    • Strobe Rate: 0 to 20 Hz
    • Move-in-Black: Yes
    • Dim Curves: 4

    CONSTRUCTION / PHYSICAL

    • Dimensions: 14 x 8.8 x 25.0 in (360 x 224 x 636 mm)
    • Weight: 47.4 lb (21.5 kg)
    • Exterior Colour: Black
    • Housing Material: High-impact flame-retardant polymer

    CONNECTIONS

    • Power Connection: Edison plug to Seetronic Powerkon IP65
    • Power Input: Seetronic Powerkon IP65
    • Data Connectors: 3-pin and 5-pin XLR, Amphenol XLR Net RJ45 Connectors in/out
    • Cable Length (power): 5 ft (1.5 m)

    CONTROL

    • Control Protocol: Art-Net, sACN, DMX, RDM, W-DMX
    • DMX Channels: 22 or 29
    • Art-Net Channels: 22 or 29
    • Modes/Personalities: 2 personalities (22, 29)

    ELECTRICAL

    • Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)
    • Power Linking: 2 units @ 100 V; 2 units @ 120 V; 5 units @ 208 V; 5 units @ 230 V; 5 units @ 240 V
    • Power and Current: 554 W, 5.54 A @ 100 V, 60 Hz[6.0 A in-rush]
    • Power and Current: 542 W, 4.53 A @ 120 V, 60 Hz[7.0 A in-rush]
    • Power and Current: 522 W, 2.58 A @ 208 V, 60 Hz[15.0 A in-rush]
    • Power and Current: 521 W, 2.33 A @ 230 V, 50 Hz[15.0 A in-rush]
    • Power and Current: 521 W, 2.26 A @ 240 V, 50 Hz[15.0 A in-rush]
    • Power and Current (resting): 77 W, 0.904 A @ 100 V, 60 Hz
    • Power and Current (resting): 77 W, 0.701 A @ 120 V, 60 Hz
    • Power and Current (resting): 76 W, 0.418 A @ 208 V, 60 Hz
    • Power and Current (resting): 73 W, 0.375 A @ 230 V, 50 Hz
    • Power and Current (resting): 74 W, 0.368 A @ 240 V, 50 Hz

    CERTIFICATIONS / QUALIFICATIONS

    • CE, MET, FCC
    • IP Rating: IP20, dry location
    • Noise Level (ambient): 37.5 dB level @ 1 m
    • Noise Level (Static - Full): 40.9 dB level @ 1 m
    • Noise Level (Static - Eco): 37.9 dB level @ 1 m
    • Noise Level (Static - Auto): 38.4 dB level @ 1 m
    • Noise Level (Max): 45.5 dB level @ 1 m
    • Temperature (startup): -4 °F to 113 °F (-20 °C to 45 °C)
    • Temperature (operating): -22 °F to 113 °F (-30 °C to 45 °C)

    Manufacturer: Chauvet
