JBL Control 19CS 8" In-Ceiling Sub

Description

The Control 19CS uses advanced proprietary technologies to produce powerful bass from a low profile in-ceiling design.

Main Features

  • Unique Nested Chamber design and Linear Dynamic Aperture port design
  • Delivers high output from a compact enclosure
  • SonicGuard overload protection allows higher operational levels and improved system reliability
  • Long excursion 200 mm (8 in) driver
  • Packaged with grille, backcan and tile rails for fast installation and easy stocking
  • Simple installation and wire connection method
  • Priced and Sold Individually

Product Specifications

General

  • Frequency Range: 42 Hz - 200 Hz
  • Power Capacity: 200 W Continuous Program Power
  • Nominal Sensitivity: 95 dB SPL, 1W @ 1 m (3.3 ft) in ceiling near corner (π/2) 89 dB SPL, 1W @ 1 m (3.3 ft) in center of ceiling (2π)
  • Nominal Coverage Angle: 180° conical coverage
  • Rated Maximum SPL: 115 dB @ 1 m (3.3 ft) in ceiling near corner (π/2)
  • Nominal Impedance: 8 ohms
  • Low Frequency200 mm (8.0 in) Polypropelene cone.
  • 38 mm (1.5 in) coil on aluminum former
  • Enclosure MaterialBackcan: Formed steel Baffle/Rim: Medium impact polystyrene, fire rated UL94V-0
  • Overload ProtectionFull-range power limiting to protect network and transducers. (On Control 19CS, not on Control 19CST)
  • TerminationsRemovable locking connector with screw-down terminals. 2 input terminals and 2 loop-thru output terminals. Max. wire size 12 AWG (2.5 mm2)
  • Safety Agency RatingIn accordance with IEC60849 / EN60849. Suitable for use in air handling spaces, per U.L.-2043, U.L.-1480, NFPA90, NFPA70A.

Physical & Dimensions

  • Height: 345mm
  • Diameter: 345mm
  • Front of Ceiling Tile to back of backcan: 318mm
  • Cutout Size: 305mm
  • Net Weight (ea): 5.5 kg (12 lb
  • Shipping Weight (pair)Control 19CS: T12.7 kg (28 lb)

Manufacturer: JBL

Related Collections:

Product form

SKU: JBL-CONTROL-19CS

Out of stock

£351.00 Incl. VAT

    Delivery informationDelivery information

    There is a free standard delivery option for most UK orders as well as a £2.99 option which means your order will arrive faster than normal.

    For standard delivery your order should arrive within 2-5 working days. For the faster option it should be 1-3 working days.

    If you're from Northern Ireland there will be a £5 surcharge for heavier items. If you're buying a light item (under 2kg) please let us know as we may be able to refund your postage after the purchase.

    Buy now pay laterBuy now pay later

    Paypal Pay in 3 lets you spread your purchase interest free over 3 separate payments.

    If you'd like to use Paypal Pay in 3, please perform the following steps.

    1. Add the item to your cart as normal.

    2. Check out with Paypal.

    3. Log into Paypal.

    4. You should see a screen detailing the item costs. Scroll down and you should see an option for "Pay in 3".

    5. Continue the checkout process.

    1/3 of the purchase price will be taken immediately and then the rest over the next 2 months the rest of the payment will be taken.

    Please see more info about the service here.

    As with any sort of buy now pay later, please only use this service for added convenience when making a bigger purchase. It should only be used if you're 100% sure you can make all of the payments on time.

    Description

    The Control 19CS uses advanced proprietary technologies to produce powerful bass from a low profile in-ceiling design.

    Main Features

    • Unique Nested Chamber design and Linear Dynamic Aperture port design
    • Delivers high output from a compact enclosure
    • SonicGuard overload protection allows higher operational levels and improved system reliability
    • Long excursion 200 mm (8 in) driver
    • Packaged with grille, backcan and tile rails for fast installation and easy stocking
    • Simple installation and wire connection method
    • Priced and Sold Individually

    Product Specifications

    General

    • Frequency Range: 42 Hz - 200 Hz
    • Power Capacity: 200 W Continuous Program Power
    • Nominal Sensitivity: 95 dB SPL, 1W @ 1 m (3.3 ft) in ceiling near corner (π/2) 89 dB SPL, 1W @ 1 m (3.3 ft) in center of ceiling (2π)
    • Nominal Coverage Angle: 180° conical coverage
    • Rated Maximum SPL: 115 dB @ 1 m (3.3 ft) in ceiling near corner (π/2)
    • Nominal Impedance: 8 ohms
    • Low Frequency200 mm (8.0 in) Polypropelene cone.
    • 38 mm (1.5 in) coil on aluminum former
    • Enclosure MaterialBackcan: Formed steel Baffle/Rim: Medium impact polystyrene, fire rated UL94V-0
    • Overload ProtectionFull-range power limiting to protect network and transducers. (On Control 19CS, not on Control 19CST)
    • TerminationsRemovable locking connector with screw-down terminals. 2 input terminals and 2 loop-thru output terminals. Max. wire size 12 AWG (2.5 mm2)
    • Safety Agency RatingIn accordance with IEC60849 / EN60849. Suitable for use in air handling spaces, per U.L.-2043, U.L.-1480, NFPA90, NFPA70A.

    Physical & Dimensions

    • Height: 345mm
    • Diameter: 345mm
    • Front of Ceiling Tile to back of backcan: 318mm
    • Cutout Size: 305mm
    • Net Weight (ea): 5.5 kg (12 lb
    • Shipping Weight (pair)Control 19CS: T12.7 kg (28 lb)

    Manufacturer: JBL
